USA:
GF 211 is a 6.0 mil gloss clear light emboss vinyl laminate with a permanent acrylic pressure sensitive adhesive formulatednfor exceptional clarity. This product is produced on a 1.5 mil polyester clear liner designed to provide an extremely smoothnadhesive coating to achieve optimal clarity. GF 211 can be paired with approved print films to create floor graphics for tile andncarpet. GF 211 has been rated for slip resistance based on multiple testing methods.
GF 211-54
GF 211 is a 6.0 mil gloss clear light emboss vinyl laminate with a permanent acrylic pressure sensitive adhesive formulated for exceptional clarity.
Technical Specification
| Applications | Concept® 211 is intended for use as the overlaminating film to produce Traffic Graffic® floor decals. The adhesive is formulated to adhere to most common printing inks. However, specific formulations must be tested before use. Some ink may contain excessive flow additives that could reduce adhesion of this product. Test before production. |
| Slip Resistance | Concept® 211 is classified under UL 410 for floor graphics overlay applications |
| Thickness | Film: 6 mils. Adhesive: .8 to 1.1 mils. Liner: 4 mils. (Thickness variance +/- 10%) |
| Temperature Ranges | Minimum application temperature: +40° F Service temperature range: -40°F to +200°F. |
| Durability | Concept® 211 will function as a Traffic Graphic overlaminate for six (6) month under normal use. |
| Expected Exterior Exposure | This product is designed for interior applications. Exterior resistance has not been determined. |
| Adhesion | To stainless steel 40 oz/in. Tested according to PSTC-101 Method A with 24-hour dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
| Water Resistance | Excellent |
| Humidity Resistance | Excellent. |
| Storage Stability | 12-months shelf life when stored at 70°F and 50% relative humidity. |
| Product Codes | 211-54 (54” x 150’ roll) |
| Recommendations | Completely evaporate ink solvents before application. Failure to do so may facilitate solvent penetration resulting in premature vinyl degradation. |
Additional information
| Weight | 42 lbs |
|---|---|
| Dimensions | 57 × 7 × 7 in |
