With greater color and performance, the new generation VG2 was built for your success
TrueVIS VG2 Series
| VG2-640 | VG2-540 | ||
|---|---|---|---|
| Printing method | Piezo ink-jet method | ||
| Media | Width | 12.4 to 64 in. (315 to 1,625 mm) | 10.8 to 54 in. (275 to 1,371 mm) |
| Thickness | Max. 39 mil (1.0 mm) with liner, for printing Max. 16 mil (0.4 mm) with liner and 9 mil (0.22 mm) without liner, for cutting |
||
| Roll outer diameter | Max. 8.3 in. (210 mm ) | ||
| Roll weight | Max. 88 lb. (40 kg) | Max. 66 lb. (30 kg) | |
| Core diameter (*1) | 3 in. (76.2 mm) or 2 in. (50.8 mm) | ||
| Printing/cutting width (*2) | Max. 63 in. (1,600 mm) | Max. 53 in. (1,346 mm) | |
| Ink | Type | TrueVIS INK 500 ml pouch (only white 250 ml) | |
| Colors | 8 colors (Cyan, Magenta, Yellow, Black, Light Black, Orange, Green, and White) 8 colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, and White) 8 colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, and Orange) 7 colors (Cyan, Magenta, Yellow, Black, Light Black, Orange and Green) 4 colors (Cyan, Magenta, Yellow, and Black) |
||
| Printing resolution (dots per inch) | Max. 1200 dpi | ||
| Cutting speed | 0.4 to 11.8 in/s (10 to 300 mm/s) | ||
| Blade force (*3) | 30 to 500 gf | ||
| Blade | Type | Roland CAMM-1 series blade | |
| Offset | 0.0 to 59.1 mil (0.000 to 1.500 mm) | ||
| Software resolution (when cutting) | 0.98 mil/step (0.025 mm/step) | ||
| Distance accuracy (when printing) (*4) (*5) | Error of less than ±0.3% of distance traveled or ±11.8 mil (±0.3 mm), whichever is greater | ||
| Distance accuracy (when cutting) (*4) | Error of less than ±0.4% of distance traveled or ±11.8 mil (±0.3 mm), whichever is greater When distance correction has been performed (when the setting for [CUTTING MENU] – [CALIBRATION] has been made): Error of less than ±0.2% of distance traveled or ±3.9 mil (±0.1 mm), whichever is greater |
||
| Repeatability (when cutting) (*4) (*6) | ±3.9 mil (±0.1 mm) or less | ||
| Alignment accuracy for printing and cutting (*4) (*7) | ±19.7 mil (±0.5 mm) or less | ||
| Alignment accuracy for printing and cutting when reloading media (*4) (*8) | Error of less than ±0.5% of distance traveled, or ±0.2 in. (±3 mm), whichever is greater | ||
| Media heating system (*9) | Print heater set temperature: 86 to 112°F (30 to 45°C) Dryer set temperature: 30 to 50°C (86 to 122°F) |
||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||
| Power-saving function | Automatic sleep feature | ||
| Power requirements | AC 100 to 120 V ±10%, 8.0 A, 50/60 Hz or AC 220 to 240 V ±10%, 4.1 A, 50/60 Hz |
||
| Power consumption | During operation | Approx. 1,090 W | |
| Sleep mode | Approx. 40 W | ||
| Acoustic noise level | During operation | 63 dB (A) or less | |
| During standby | 53 dB (A) or less | ||
| Dimensions (with stand) | 116 [W] × 28.8 [D] × 51.6 [H] in. (2,945 (W) × 730 (D) × 1,310 (H) mm) |
105.8 [W] × 28.8 [D] × 51.6 [H] in. (2,685 (W) × 730 (D) × 1,310 (H) mm) |
|
| Weight (with stand) | 451.9 lb. (204 kg) | 421 lb. (188 kg) | |
| Environment | During operation | Temperature: 68 to 90°F (20 to 32°C), Humidity: 35 to 80%RH (no condensation) |
|
| Not operating | Temperature: 41 to 104°F (5 to 40°C), Humidity: 20 to 80%RH (no condensation) |
||
| Included items | Dedicated stands, power cord, media clamps, media holders, replacement blade for separating knife, manuals, etc. | ||
* U.S. only. For Canada, Latin America and Caribbean pricing, please contact an Authorized Roland DGA Dealer in your area.
** For 60 months, OAC
Engineered to exceed the quality and production needs of today’s most demanding professionals, the TrueVIS VG2 is everything you could ever want in a printer/cutter and a whole lot more.
Vehicle Wraps and Graphics
VEHICLE WRAPS AND GRAPHICS
Certified for use with 3M and Avery products, the VG2 offers vehicle wrap graphics with outstanding color and long-lasting results.
Backlits
BACKLITS
Print/cut onto specialty materials to create backlit displays full of brilliant light and color that immediately stand out from other signs and promotions.
Wall Graphics
WALL GRAPHICS
Add artistic finishes to residential, office, and retail walls and floors with the output quality and machine versatility of VG2– reproduce exact logos and branding with new color options.
Die-Cut Labels and Decals
DIE-CUT LABELS AND DECALS
Print/cut thousands of labels and decals in one print job with non-skew precision, speed and ease.
Heat Transfer Graphics
HEAT TRANSFER GRAPHICS
Making short-run graphics for t-shirts, bags, and other applications has never been easier with increased print/cut accuracy and automated machine features.
Signs and Banners
SIGNS AND BANNERS
Produce graphics that are durable for up to three years outdoors without lamination— new 3M and Avery certified inks perform brilliantly on a wide range of coated and uncoated media.
Get detailed color results or create bold, vivid graphics with TR2 inks. With three different configurations in CMYK, plus additional Light Cyan, Light Magenta, Light Black, White or Orange or new Green ink*, you have more color freedom and control than ever before. The addition of Green or Orange Ink also means that you can consistently reproduce specific brand colors for your clients and customers. TR2 ink is GREENGUARD Gold certified for indoor air quality.
*Green ink configuration available on installation of new devices only and must be selected at time of purchase. Contact authorized Roland DGA dealer for details
Global print material providers, 3M and Avery Dennison are now offering warranty coverage for graphics printed with the VG2 and TR2 ink— with Avery Dennison offering warranty coverage for same day print, lamination and wrapping.
The combination of VG2 and new TR2* ink is certified for long-lasting results under the 3M™ MCS™ Warranty. It provides your customers with assurance of the quality and reliability of their graphics.
*The 3M™ MCS™ Warranty covers printing onto 3M products with standard TR2 inks.
The VG2 with new TR2** ink is also certified by Avery Dennison’s ICS Performance Guarantee which provides added protection and warrants prints for same-day lamination.
**The Avery Dennison™ ICS Performance Guarantee covers printing onto Avery Dennison products with standard TR2 inks.
Reach new areas of color, including purples, reds, greens, and other challenging hues— elevating all your print output with True Rich Color 2. Improve reproduction of specific brand colors and combine neutral grays, smooth gradations, and natural skin tones to produce color quality of incomparable realism and complexity.
Custom crop in a few easy clicks and improve accuracy on long runs of labels, heat transfers and decals using the new Crop Mark by Row function in VersaWorks 6 software. When handling intricate files, you can also select Crop Mark by Image.
 |
Improved workflow The VG2 is turning up machine efficiency with faster job setup time and sequence, reduced ink maintenance consumption, and other productivity features. |
 |
New Media Take-Up An included TUC4 take up system offers two modes to expertly handle everything from thin films to heavy canvas materials and providing take-up stability for a smooth post process. |
 |
Nozzle Mask Function If a nozzle on the printhead is misfiring, you can minimize printer downtime with the ability to turn off a specific nozzle band to allow continued production. |
 |
Roland DG Mobile Panel Bluetooth enabled printer management allows you to test print, clean and troubleshoot your VG2 from your tablet or smartphone. |
Watch the Video
Have you considered producing industry compliant traffic graphics on reflective media as a valuable new revenue source?
Effortlessly manage your print output with the latest edition of the world’s most popular RIP software.
Improved speed and file handling with HARLEQUIN RIP dual core engine and 64-bit native processing.
Simplified new drag-and-drop interface to quickly add jobs to the print queue.
Five print queues, five hot folders and unlimited queue settings.
Built in spot color libraries include Pantone and Roland DG Color libraries.
All the advanced and easy cropping, tiling, nesting and other features of VersaWorks.
Match color output between different printers and print modes from a single printer with Printer Color Match Settings that integrates profiling tools such as the i1 Pro3 and new VW-S1 color measuring tool. Read the FAQ’s
Create cut data directly in VersaWorks 6 by extracting PDF data from your design file to use as a cut line— changing vector data into cut line data, merging multiple cut lines together, creating perf cut lines, and other intuitive features.
For over 35 years, Roland DGA has provided industry professionals with the most advanced and reliable machines, backed by unmatched customer service and technical support. The VG2 is supplied with a Two-Year Trouble-Free Warranty to give you added peace-of-mind and machine support.
| Weight | 380 lbs |
|---|---|
| Dimensions | 28.8 × 105.8 × 51.6 in |
