GF 230 is a Premium 2.4 mil calendered Gloss white vinyl digital media with a grey permanent repositionable acrylic adhesive on an air-egress liner. This film is designed to accept a variety of solvent, latex and UV curable inks common to wide format digital printing systems. The grey permanent adhesive offers excellent opacity and exceptional repositionable qualities. GF 230 AutoMark Premium 2.4 mil calendered gloss white vinyl digital media is specifically engineered for use in most vehicle wrap and decal applications. The 90# Air Egress Layflat liner allows for good lay-flat and air-free application.
GF 230-60
GF 230 is a Premium 2.4 mil calendered Gloss white vinyl digital media with a grey permanent repositionable acrylic adhesive on an air-egress liner.
Technical Specification
| Applications | Concept® 230 Premium 2.4-mil Calendared gloss white vinyl digital media is designed to be applied to corrugations, riveted surfaces, flat and slight to moderate curves. The construction can be used on vans, trucks, sedans of all sizes, fleet and recreational vehicles. Application surface should always be cleaned, tested and checked for defects before applying AutoMARK™ Concept 230 digital vehicle wrap media. Recommend overlaminates Concept® 231 UV Gloss and ConceptÒ 240 UV Matte finishes. |
| Thickness | Film: 2.4 mils. Adhesive: 1.0 to 1.3 mils. Liner: 7.0 mils. (Thickness variance +/- 10%) |
| Dimensional Stability | Good. |
| Temperature Ranges | Minimum application temperature: +40° F Service temperature range: -40°F to +200°F. |
| Adhesion | To stainless steel 40 oz/in. When tested according to PSTC-101 Method A with 24 hr. dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
| Water Resistance | Excellent Test if immersed |
| Humidity Resistance | Excellent |
| Solvent Resistance | Excellent |
| Expected Exterior Exposure | Up to 7 years. Performance can vary depending on UV exposure |
| Storage Stability | 1-year shelf life when stored at 70°F and 50% relative humidity. |
| Product Codes | 230-54 54” x 150′ 230-60 60” x 150′ |
Additional information
| Weight | 56 lbs |
|---|---|
| Dimensions | 63 × 7 × 7 in |
