GF 400 is a 3.0 mil gloss clear UV pressure sensitive vinyl laminate that offers resistance to ultraviolet degradation with a permanent acrylic adhesive on a smooth 53# liner. This calendered PVC laminate also protects graphics from abrasion and moisture. GF 400 is best applied by the cold laminating process without the addition of heat and is designed to protect digital and screen printed images for exhibit and display graphics. GF 400 can be used in most instances where an overlay with a high gloss finish is required on interior or exterior applications.
GF 400-54
GF 400 is a 3.0 mil gloss clear UV pressure sensitive vinyl laminate that offers resistance to ultraviolet degradation with a
permanent acrylic adhesive on a smooth 53# liner.
Technical Specification
| Applications | Concept® 400 gloss overlaminating vinyl film is designed to protect digital image prints and screen printed images for exhibit and display graphics. Can be used in most instances where an overlay with a high gloss finish is required on interior or exterior applications. |
| Thickness | Film: 3.0 mil. Adhesive: 0.8 to 1.0 mils. Liner: 4.0 mils. (Thickness variance +/- 10%) |
| Dimensional Stability | Good |
| Temperature Ranges | Minimum application temperature: +40° F Service temperature range: -40°F to +180°F. |
| Expected Exterior Exposure | Up to 4 years under normal conditions.(vertical surfaces) |
| Adhesion | To stainless steel 40 oz/in. PSTC-101 Method A with 24 hour dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
| Light Transmission | Approximately 90%@ 550 nm |
| Gloss 20° Gardner | Initial ≥ 60 |
| Storage Stability | 1-year shelf life when stored at 70°F and 50% relative humidity. |
| Product Series | Concept® 400 Size Offering Part# 400-30 (30”x150’) Part# 400-54 (54”x150’) Part# 400-38 (38”x150’) Part# 400-60 (60”x150’) |
Additional information
| Weight | 38 lbs |
|---|---|
| Dimensions | 57 × 7 × 7 in |
