GF 255 OptiMark is a 3.0 mil optically clear high gloss flexible calendared PVC film coated with an optically clear solvent removable pressure sensitive adhesive laminated to a 2.0 mil traction backed polyester liner. This film is designed to accept a variety of solvent-based, UV curable and latex inks common to wide format digital printing systems. The adhesive system provides clean removal from glass for up to one year under normal exposure conditions. The 2.0 mil polyester liner has a traction coating to aide in processing on common digital printers.
GF 255-54
GF 255 OptiMark is a 3.0 mil optically clear high gloss flexible calendared PVC film coated with an optically clear solvent removable pressure sensitive adhesive laminated to a 2.0 mil traction backed polyester liner. T
Technical Specification
Applications | Concept® 255 is designed for temporary short term interior or exterior signage, decals and point-of-purchase displays on windows where optical clarity is required. |
Thickness | Fabric: 2.8 to 3.2 mils. Adhesive: .7 to 1.0 mils. Liner: 2.0 mils. (Thickness variance +/- 10%) |
Dimensional Stability | Good |
Temperature Ranges | Minimum application temperature: +40° F Service temperature range: -40°F to +180°F. |
Expected Exterior Exposure | ConceptÒ 255 contains UV inhibitors to extend exterior life. However any clear vinyl film can yellow with exposure to UV radiation. Must be tested for specific usage. |
Adhesion | To Glass 2 Oz/ in. To Stainless Steel 2 Oz/ in. Tested according to PSTC-1 with 24-hour dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
Water Resistance | Good |
Humidity Resistance | Good |
Storage Stability | One (1) year shelf life when stored at 70°F and 50% relative humidity. |
Product Code | 255-54 (54″ x 150’ roll) |
Recommendations | Completely evaporate inkjet solvents before application. Failure to do so may facilitate solvent penetration resulting in product failure. |
Additional information
Weight | 36 lbs |
---|---|
Dimensions | 57 × 7 × 7 in |
