GF 106 Mounting Film is a double-coated pressure sensitive 1.0 mil polyester film with optically clear permanent acrylic adhesive. Two 1.5 mil polyester film liners are used to maintain excellent adhesive clarity. This clear mounting film offers protection from UV light, abrasion, moisture and other environmental exposures. This product is designed for laminating thin flexible films and papers under 10 mils in total thickness. It can be laminated by the cold laminating process without the addition of heat
GF 106 Optical Clear 51
GF 106 Mounting Film is a double-coated pressure sensitive 1.0 mil polyester film with optically clear permanent acrylic adhesive.
Technical Specification
| Applications | Transparency Mounting Film is designed to mount backlit transparencies to glass, Plexiglasâ or other clear substrates in light box applications. The product also provides distortion-free face mounting of prints to these same clear substrates. |
| Thickness | Film: 1.0 mils. Adhesive: 1.3 to 1.7 mils each side. Liner: 1.5 mils. (Thickness variance +/- 10%) |
| Dimensional Stability | Good. |
| Temperature Ranges | Minimum application temperature: +40° F Service temperature range: -40°F to 200°F. |
| Expected Exterior Exposure | Up to 1 year under normal exposure conditions. |
| Adhesion | To stainless steel: 48 oz/in. Tested according to PSTC-101 Method A procedures. 24 hr. dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
| Light Transmission | Approximately 84% @ 550nms. |
| Storage Stability | 1-year shelf life when stored at 70°F and 50% relative humidity. |
Additional information
| Weight | 35 lbs |
|---|---|
| Dimensions | 54 × 7 × 7 in |
