GF 109 is a 5.0 mil scratch resistant clear laminate with a textured matte finish. This laminating film is an inexpensive and durable alternative to polycarbonate film. It has a permanent acrylic pressure sensitive adhesive formulated for exceptional clarity. Produced on a 1.5 mil polyester clear liner, the laminate has an extremely smooth adhesive coating. GF 109 can be paired with approved print films to create graphics for tile and carpet. GF 109 has been rated for slip resistance based on multiple testing methods.
GF 109 Clear 38
GF 109 is a 5.0 mil scratch resistant clear laminate with a textured matte finish.
Technical Specification
| Applications | Scratch resistant vinyl is intended for use as the overlaminating film to produce mouse pads, counter mats, decal, floor and display overlay. The adhesive is formulated to adhere to most common printing inks. However, specific formulations must be tested before use. Some inks may contain excessive flow additives that could reduce adhesion of this product. Test before production. |
| Slip Resistance | Concept® 109 is classified under UL 410 for floor graphics overlay applications |
| Thickness | Film: 5.0 mils. Adhesive: 1.3 to 1.7 mils. Liner: 1.5 mils. (Thickness variance +/- 10%) |
| Dimensional Stability | Good. |
| Durability | Concept® 109 will function as a Traffic Graphic overlaminate for six (6) month under normal use |
| Temperature Ranges | Minimum application temperature: +40°F Service temperature range: -40°F to +200°F. |
| Expected Exterior Exposure | This product is designed for interior applications.Exterior resistance has not been determined. |
| Adhesion | To stainless steel: 48 oz/in. PSTC-101 with 24-hour dwell at 70°F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production. |
| Storage Stability | One year shelf life when stored at 70°F and 50% relative humidity. |
| Product Code | 109-38 (38” X 150’ roll) 109-51 (51” X 150’ roll) 109-54 (54” X 150’ roll) |
Additional information
| Weight | 27 lbs |
|---|---|
| Dimensions | 41 × 7 × 7 in |
